Instead of removing geometric features directly from your design, you can use virtual geometry operations to omit them from your simulations in COMSOL Multiphysics. Features can be removed from the geometry using the defeaturing tools in COMSOL Multiphysics, or they can be deactivated in Pro/ENGINEER where you have access to the history of the CAD design. The defeaturing tools in this LiveLink™ product can detect features such as small edges, faces, slivers, and fillets that will make your simulations less efficient. Small features remaining in a geometry after import can be removed at your discretion to reduce the complexity of the mesh required to simulate your design. Predefined tolerances are used as criteria for the removal and repair process. The detection, removal, and repair of geometric anomalies is automatic when you import a design from a CAD file into COMSOL Multiphysics for simulation.
LiveLink™ for PTC ® Pro/ENGINEER ® includes tools to prepare your CAD geometry for meshing and analysis. Geometry Repair Process Ensures Efficient Simulations When an optimization goal is achieved by varying the value of a parameter used for simulation, the final optimized value can be written back to the CAD file. Optimization studies and parametric sweeps can be implemented in the COMSOL environment with recurrent access to CAD design parameters. Synchronization is automatic with parametric sweeps, or when running optimization studies using the optional Optimization Module.ĬAD parameters in Pro/ENGINEER, such as the placement or length of a feature, can be directly accessed and modified by COMSOL Multiphysics. You can manually synchronize the design geometry between Pro/ENGINEER and the COMSOL environment when running both programs concurrently. Geometric entities, such as edges and faces, in the COMSOL model geometry remain associated with the corresponding features in your CAD design so that physics definitions and mesh settings are preserved throughout the revision process. Direct synchronization ensures that design updates propagate in both COMSOL Multiphysics and Pro/ENGINEER while preserving geometry associations. LiveLink™ for PTC ® Pro/ENGINEER ® provides a bidirectional interface between your designs in Pro/ENGINEER and the corresponding COMSOL model geometry. Synchronize Design Updates between COMSOL Multiphysics ® and PTC ® Pro/ENGINEER ® File export from COMSOL Multiphysics in the IGES, STEP, ACIS, and Parasolid formats allows you to share your geometry and exchange data with other CAD programs and viewers. This can be useful if you want to extend the simulation to the regions surrounding the imported solid objects of a CAD design. For example, you can combine imported geometry with geometry drawn in the COMSOL environment, and you have several possibilities for partitioning the geometry objects to create additional computational domains. By default, the imported CAD design is represented as a Parasolid geometry in COMSOL Multiphysics that can be further modified or updated. Optional support for the CATIA ® V5 file format is also available. The file import functionality included with LiveLink™ for PTC ® Pro/ENGINEER ® is derived from the CAD Import Module and supports the import of the widely used ACIS ®, Parasolid ®, STEP, and IGES formats in addition to the SOLIDWORKS ®, Inventor ®, PTC ® Pro/ENGINEER ®, and PTC ® Creo ® Parametric™ formats. Importing your 3D CAD file is another way to create a COMSOL model geometry from your design.
LiveLink™ for PTC ® Pro/ENGINEER ® includes features for CAD geometry repair, bidirectional model updates, and direct CAD parameter access from within the COMSOL environment to facilitate the integration of multiphysics simulation into your design process. Essentially any relevant physical effects and their interactions can be included in a COMSOL model to produce accurate simulations of your design.
In combination with COMSOL Multiphysics ®, you have the ability to create your design in Pro/ENGINEER and then simulate your design in the COMSOL environment.Ĭreating a COMSOL model geometry from your CAD design is straightforward and allows you to evaluate the performance of your product design in the intended operating environment. PTC ® Pro/ENGINEER ® is a versatile CAD solution that enables engineers to create parametric solid models of their product designs.
#PTC PRO ENGINEER FLASHLIGHT UPDATE#
LiveLink™ for PTC ® Pro/ENGINEER ® provides the capability to integrate 3D CAD design with multiphysics simulation to update your workflow and boost productivity. Maximize Productivity with Multiphysics Simulation and 3D CAD Design
